Power Electronics Laboratory

All laboratories
Semester
5

In the laboratory

Photographs

  • A tiled hall with wooden benches carrying trainer kits, stools, pillars and notice boards on the back wall.
  • Rows of trainer kits on a wooden bench beneath a large notice listing experiments, with more benches and a barred window beyond.

The laboratory

About

Equipment

  • 1 × AC Voltage Controller kit
  • 1 × Boost Converter kit
  • 1 × Buck Boost converter kit
  • 1 × Buck converter kit
  • 10 × Computer
  • 5 × CRO
  • 5 × Regulated DC power supply
  • 2 × SCR, TRIAC, IGBT, MOSFET Trainer kit
  • 2 × Single phase Full converter kit
  • 2 × Single phase PWM Inverter kit
  • 2 × Single phase Semi converter kit
  • 1 × Step down chopper kit
  • 1 × Step up chopper kit
  • 2 × Three phase PWM Inverter kit
